PRODUCT PARAMETERS
| Power KW | Power HP | Pressure MPa | Volume flow m³/min | Start Mode | Drive Mode | Cooling | Compression Level | Noise db(A) | Voltage V/PH/HZ | Weight KG | Dimensions (L*W*H） mm | Outlet Diameter imch/mm |
| 185KW | 250HP | 0.7 | 9.60-32.0 | VSD Soft Start | Integrated Direct Drive | Air Cooling | Single stage | 78±2 | 380V/50HZ | 4200 | 2800*1900*1950 | DN100 |
| 0.8 | 9.15-30.5 | |||||||||||
| 1 | 7.25-27.5 | |||||||||||
| 220KW | 300HP | 0.7 | 11.0-36.7 | VSD Soft Start | Integrated Direct Drive | Air Cooling | Single stage | 78±2 | 380V/50HZ | 4600 | 2800*1900*1950 | DN100 |
| 0.8 | 10.3-34.5 | |||||||||||
| 1 | 9.06-30.2 |
PRODUCT ADVANTAGES
1. Precise control
Since the variable frequency compressor uses an advanced control system, it can achieve precise control of the operating frequency of the PM VSD compressors to meet the air consumption requirements under different working conditions. This can not only reduce energy consumption, but also improve the operating efficiency of the compressor.
2. Fast load change conversion
The load change conversion speed of the variable frequency air compressor is significantly improved, realizing on-demand air supply and instantaneous adjustment, effectively avoiding overpressure or underpressure, and improving the overall operating efficiency and stability.
3.The starting current is small, basically equal to the rated current.
